Product Summary

Infineon, Formerly Eupec

Standard SCR Power Modules, TT Series
Item# TT92N14KOF - POWER MODULE 92A 1400V DUAL-SCR
TT Series Information
  • Three Standard SCR/SCR Circuits
  • Blocking Voltages to 3600 Volts
  • High Thermal Efficiency
  • 2500 Vrms Isolation
  • Industry Standard Packages

Parametrics

Item Number:   TT92N14KOF
Manufacturer:   Infineon, Formerly Eupec
Item Category:   Power Modules
Subcategory:   Standard SCR
Series:   TT
  It (avg):   92 Amps
  It (RMS):   160 Amps
  Vrrm:   1,400 Volts
  Circuit:
SCR Doubler w/aux Cathode [show info]
  Height (mm) Nominal:   30 MilliMeters
  Width (mm) Nominal:   20 MilliMeters
  Depth (mm) Nominal:   92 MilliMeters
  Tq:   150 MicroSeconds
  Igt:   120 MilliAmps
  di/dt (Amps/MicroSec.):   150
  dv/dt (Volts/MicroSec.):   1,000
  Aux. Cathode(s):   Yes
  Mounting Centers:   80 MilliMeters
  Comments:   Lead sets sold separately.
  Diag No.:   POWERMOD_SCR_SIZE_1
  Picture No.:   POWERMOD_SCR_SIZE_1
  H x W x D (in.):   1.18 x .79 x 3.62
  Net Weight:   5.64 oz
