MAX4614CSD

MAX4614CSD, single-pole/single-throw (SPST) analog switch, SOP, -0.3V to +6V, ±75mA, Maxim

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.90~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	1.00 / Piece
10 ~ 100 :	0.90 / Piece
100 ~ 1000 :	0.90 / Piece

PartNumber:: MAX4614CSD

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 06+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Rose's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-11

From Other Seller

Part Number:MAX4614CSD
US $0.90 - 1.00
Quantity:

piece

Product Summary

The MAX4614CSD is a quad, low-voltage, high-speed, single-pole/single-throw (SPST) analog switch. The device is pin compatible with the industry-standard analog switch. On-resistance (10Ω max) is matched between switches to 1Ω max and is flat (1Ω max) over the specified signal range. The MAX4614CSD handles V+ to GND analog signal levels. Maximum off-leakage current is only 1nA at TA = +25℃ and 6nA at TA = +85℃. The applications of the MAX4614CSD include Battery-Operated Equipment, Audio/Video Signal Routing, Low-Voltage Data-Acquisition Systems, Sample-and-Hold Circuits and Communication Circuits.

Parametrics

MAX4614CSD absolute maximum ratings: (1)(Voltages referenced to GND), V+, IN_: -0.3V to +6V; (2)COM_, NO_, NC_: -0.3V to (V+ + 0.03V); (3)Continuous Current (any terminal): ±75mA; (4)Peak Current (NO_, NC_, COM_),(pulsed at 1ms, 10% duty cycle): ±200mA; (5)Continuous Power Dissipation: 500mW; (6)Operating Temperature Ranges: 0℃ to +70℃; (7)Storage Temperature Range: -65℃ to +150℃; (8)Lead Temperature (soldering, 10sec): +300℃

Features

MAX4614CSD features: (1)Fast Switching Times: 12ns tON, 10ns tOFF; (2)Pin Compatible with Industry-Standard; (3)Guaranteed On-Resistance: 10Ω max (+5V supply); 20Ω max (+3V supply); (4)Guaranteed Match Between Channels (1Ω max); (5)Guaranteed Flatness Over Signal Range (1Ω max); (6)<6nA Off-Leakage Current Over Temperature (TA = +85℃); (7)Rail-to-Rail; (8)Signal Handling; (9)TTL/CMOS-Logic Compatible.
