Product Summary
The ADM485ARZ is a differential line transceiver suitable for high speed bidirectional data communication on multipoint bus transmission lines. The ADM485ARZ is designed for balanced data transmission and complies with both EIA Standards RS-485 and RS-422. The part contains a differential line driver and a differential line receiver. Both the driver and the receiver may be enabled independently. When disabled, the outputs are tristated.
Parametrics
ADM485ARZ absolute maximum ratings:(1)VCC:+7 V; (2)Inputs:Driver Input (DI):–0.3 V to VCC + 0.3 V; Control Inputs (DE, RE):–0.3 V to VCC + 0.3 V; Receiver Inputs (A, B):–14 V to +14 V; (3)Outputs:Driver Outputs:–14 V to +14 V; Receiver Output:–0.5 V to VCC +0.5 V; (4)Power Dissipation 8-Pin DIP(θJA,Thermal Impedance:+130°C/W):500 mW;(5)Power Dissipation 8-Pin SOIC(θJA, Thermal Impedance:+170°C/W): 450 mW; (6)Power Dissipation 8-Pin Cerdip(θJA, Thermal Impedance:+125°C/W) :500 mW; (7)Operating Temperature Range: Commercial (J Version):0°C to +70°C; Industrial (A Version) :–40°C to +85°C; Storage Temperature Range:–65°C to +150°C; (8)Lead Temperature (Soldering, 10 sec) : +300°C; (9)Vapour Phase (60 sec) :+215°C; (10)Infrared (15 sec) :+220°C.
Features
ADM485ARZ features: (1)Meets EIA RS-485 Standard; (2)5 Mb/s Data Rate; (3)Single +5 V Supply; (4)–7 V to +12 V Bus Common-Mode Range; (5)High Speed, Low Power BiCMOS; (6)Thermal Shutdown Protection; (7)Short Circuit Protection; (8)Zero Skew Driver; (9)Driver Propagation Delay: 10 ns; (10)Receiver Propagation Delay: 25 ns; (11)High Z Outputs with Power Off; (12)Superior Upgrade for LTC485.
Diagrams
