Product Summary
The R1WV6416RSA-5SI is a low voltage 64-Mbit static RAM organized as 4,194,304-word by16-bit, fabricated by Renesas’s high-performance 0.15um CMOS and TFT technologies. The R1WV6416RSA-5SI is suitable for memory applications where a simple interfacing, battery operatingand battery backup are the important design objectives.The R1WV6416RSA-5SI Series is provided in 48-pin thin small outline package [TSOP (I): 12mm x 20mm withpin pitch of 0.5mm], 52-pin micro thin small outline package [μTSOP (II): 10.79mm x 10.49mm with pin pitchof 0.4mm] and 48-ball fine pitch ball grid array [f-BGA] package.
Parametrics
R1WV6416RSA-5SI absolute maximum ratings: (1)Power supply voltage relative to Vss, Vcc: -0.5 to +4.6V; (2)Terminal voltage on any pin relative to Vss, VT: -0.5 to Vcc +0.3V; (3)Power dissipation, PT: 0.7W; (4)Operation temperature, Topr, Rver: 0 to +70℃; Iver: -40 to +85℃; (5)Storage temperature range, Tstg: -65 to 150℃; (6)Storage temperature range under bias, Tbias, Rver: 0 to +70℃; Iver: -40 to +85℃.
Features
R1WV6416RSA-5SI features: (1)Single 2.7~3.6V power supply; (2)Small stand-by current: 8 μA (3.0V, typical); (3)No clocks, No refresh; (4)All inputs and outputs are TTL compatible; (5)Easy memory expansion by CS1#, CS2, LB# and UB#; (6)Common Data I/O; (7)Three-state outputs: OR-tie Capability; (8)OE# prevents data contention on the I/O bus.
