Product Summary
The AD8676BRZ precision operational amplifier offers ultralow offset, drift, and voltage noise combined with very low input bias currents over the full operating temperature range. The AD8676BRZ is a precision, wide bandwidth op amp featuring rail-torail output swings and very low noise. Operation is fully specified from ±5 V to ±15 V. And the AD8676BRZ is used in precision instrumentation, PLL filters, laser diode control loops, strain gage amplifiers and so on.
Parametrics
AD8676BRZ absolute maximum ratings: (1)Supply Voltage:±18 V ; (2)Input Voltage :±V Supply-1.5 V; (3)Differential Input Voltage: ±0.7 V; (4)Output Short-Circuit Duration to GND :Indefinite ; (5)Storage Temperature Range RM, R Packages :-65°C to +150°C ; (6)Operating Temperature Range :-40°C to +125°C ; (7)Junction Temperature Range RM, R Packages :-65°C to +150°C ; (10)Lead Temperature Range (Soldering, 10 sec):300°C.
Features
AD8676BRZ features: (1)Very low voltage noise 2.8 nV/Hz @ 1 kHz ; (2)Rail-to-rail output swing ; (3)Low input bias current: 2 nA maximum; (4)Very low offset voltage: 12 μV typical ; (5)Low input offset drift: 0.6 μV/°C maximum ; (6)Very high gain: 120 dB ; (7)Wide bandwidth: 10 MHz typical ; (8)±5 V to ±18 V operation.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 AD8676BRZ |
|
IC OPAMP GP R-R 10MHZ DUAL 8SOIC |
Data Sheet |
|
|
||||||||||||||||||
|
AD8676BRZ-REEL |
|
IC OPAMP GP R-R 10MHZ DUAL 8SOIC |
Data Sheet |
|
|
||||||||||||||||||
|
AD8676BRZ-REEL7 |
|
IC OPAMP GP R-R 10MHZ DUAL 8SOIC |
Data Sheet |
|
|
||||||||||||||||||
